The components are arranged in the following groups:
Designation Function, use Components (examples)
Line-side power components Switching the energy supply and to comply with EMC
regulations
• Fuses
• Contactors
• Reactors
• Filters
Line Modules Central energy supply into the DC link
• Smart Line Modules
DC link components Additional components for the DC link
• Braking Modules
• Capacitor Module
• Control Supply Modules
Motor Modules Inverters, which draw energy from the DC link and
supply the connected motors
• Motor Modules
Motor-side power components Additional components on the output side
• Motor reactors
Control Units Processing cross-axis drive and technological func‐
tions
• Control Unit
Additional system components Extend the functionality, provide various interfaces to
encoders and process signals
• Option Board
• Communication Board
• Terminal Modules
3.1.2 Mixed operation of SINAMICS S120 and S220 components
Overview
Mixed operation of SINAMICS S120 booksize and S220 booksize components is possible.
Requirement
WARNING
Danger to life due to unsuitable 󹪝rmware version
Operating SINAMICS S220 booksize components with an unsuitable 󹪝rmware version can
result in unsafe operating states. For example, it can lead to converter components
overheating, a motor unexpectedly accelerating or safety functions not functioning.
• When using a SINAMICS S220 Smart Line Module, use a Control Unit with 󹪝rmware V5.2 SP3
HF10 or later.
• When using a SINAMICS S220 Motor Module, use a Control Unit with 󹪝rmware V5.2 SP3 HF9
or later.
Description
The article numbers of SINAMICS S220 booksize components start with 6SL5.
System overview
3.1Overview of the booksize system
Booksize power units
