7.2 Overview
Overview image
NN
L8L8
Figure7-1 Smart Line Modules 16 - 24kW
Table 7-1 Smart Line Modules
Rated power [kW] Width [mm] C type D type
Article number 6SL5130-
16 100 6UE21-6AC0 6UE21-6AD0
24 100 6UE22-4AC0 6UE22-4AD0
7.3 Safety instructions
7.3.1 Safety information
WARNING
Electric shock when the protective 󹪞ap of the DC link is open
Contact with live parts can result in death or serious injury.
• Only operate the components with closed protective 󹪞ap.
