8.5.5 Technical data
Technical data
Table 8-34 Single Motor Modules D type (85A to 200A)
Feature Unit Article No. 6SL5120-
1UE28-5AD0 1UE31-3AD0 1UE32-0AD0
Output data
Rated current (l
rated
)
Intermittent duty current (l
s6
) 40%
Peak current (l
max
)

A
A
A

85
113
170

132
176
264

200
230
400
Output voltage3AC V 0 … 0.707 x DC link voltage
1)
(0 ... 480V at 680VDC)
Output frequency Hz 0 ... 550
2)
Apparent power for U
DC
of 600V
Rated power IEC
3)
Rated power NEC
4)
kVA
kW
hp
62
45
60
97
75
100
147
110
150
Input data
DC link voltage (U
DC
)
Overvoltage trip
Undervoltage trip
5)
Electronics power supply

V
V
V
V

495 … 720
820
380 … 432
24
DC link current (I
DC link
) A 106 165 250
DC link capacitance μF 1880 2820 4080
Current-carrying capacity
DC link busbars
24 V DC busbars

A
A

250
20
Current consumption of the electronics
at 24VDC

A

0.75

0.75

0.8
Power loss W 770 1270 2070
Cooling air requirement m
3
/h 290 290 340
Weight kg 15 17.2 20
Cable lengths m See Chapter "Maximum permissible cable lengths (Page54)"
1)
In the case of overmodulation, a motor output voltage up to 3% higher is possible.
2)
Higher output frequencies up to a maximum of 3200Hz are possible with an additional license.
3)
Rated power of a typical standard induction motor at 3 AC 400V according to IEC 60947-4-1:2018 Annex G Table G.1
4)
Rated power of a standard induction motor at 3 AC 460 V according to NEC Table 430.250
5)
Depends on the parameterized device supply voltage
Motor Modules
8.5Motor Modules 85 A, 132 A and 200 A
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 221
