Accessories
11
11.1 DRIVE-CLiQ signal cables
11.1.1 Overview
Description
To connect the DRIVE-CLiQ interfaces of the components, the following pre-assembled and
unassembled DRIVE-CLiQ signal cables can be used:
Table 11-1 DRIVE-CLiQ signal cables
Type of DRIVE-CLiQ signal cable Description
with RJ45 connector, IP20 degree of
protection
They are used to connect components with DRIVE-CLiQ connec‐
tion. They are mainly intended for use in control cabinets.
with RJ45 connector, IP67 degree of
protection
They are used for components with DRIVE-CLiQ connection if
higher requirements must be complied with, such as mechanical
stress and resistance to oil.
The signal cables are used for connections outside the control
cabinet:
• Connections between Motor Modules and Sensor Modules
• Connections between Motor Modules and motors with
DRIVE-CLiQ interface
with RJ45 connector and M12 socket They establish the connection between components with a
DRIVE-CLiQ connection and a direct measuring system equipped
with DRIVE-CLiQ with 8-pin M12 plug. This means that measur‐
ing systems from third-party manufacturers can be directly con‐
nected to the SINAMICS S220 booksize system.
More information
Information about DRIVE-CLiQ signal cables and the possibility of establishing a direct
measuring system with DRIVE-CLiQ connection and M12 plug to a DRIVE-CLiQ component via
MOTION-CONNECT cables are described in Chapter "Connection system" on the internet:
SINAMICSS120 Booksize Power Units Equipment Manual (
https://
support.industry.siemens.com/cs/ww/en/view/109781351)
Wiring rules for DRIVE-CLiQ are provided in Chapter "Rules for wiring DRIVE-CLiQ" on the
internet:
SINAMICS S120 Function Manual Drive Functions (https://
support.industry.siemens.com/cs/ww/en/view/109781535)
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 267
