Line-side power components
6
6.1 Components for connection to the line supply
Overview
The following components are used to connect the drive line-up to the line supply:
• Disconnector unit
• Overcurrent protective device
• Line contactor (optional)
• Line lter (optional)
• Line reactor
Overview image
"$MJOFTVQQMZ
5PUIF
4NBSU-JOF.PEVMF
-JOFMUFS
PQUJPOBM
-JOFSFBDUPS
Figure6-1 Line connection with line lters and line reactors (example for Smart Line Modules)
6.2 Disconnector units
Overview
A disconnector unit is required for disconnecting the drive line-up from the supply system.
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 97
