8.3.10 Connecting the motor
8.3.10.1 Connectable cable cross-sections
Description
Table 8-12 Conductor cross-sections and tightening torques
Output current Motor connection Cable cross-sections Tightening torque
3 ... 30A
2 x 3A ... 2 x 18A
Plug with screw terminal
(6SL3162-2MA00-0AC0)
Finely stranded connection with:
0.75 ... 6mm
2
(AWG 19 ... 10)
0.5 - 0.6Nm (4.4lbf in)
Plug with push-in connection
(6SL3162-2MB00-0AC0)
-
8.3.10.2 Preparing the motor connection cable
Overview
Motors are connected to a Motor Module using a motor connection cable with a connection
plug. We recommend that you use a completely prefabricated MOTION-CONNECT power cable.
If you are using a power cable or a MOTION-CONNECT power cable that has not yet been
completely prefabricated, then you must 󹪝rst fabricate the motor connection cable.
Requirement
NOTICE
Adherence to core and stripped lengths
If the speci󹪝ed core and stripped lengths are not complied with, single cores can be damaged
or shield contact prevented.
• Comply with the speci󹪝ed core and stripped lengths.
It is not possible to self-assemble motor connection cables having a core cross-section of
10mm
2
. In this case, use pre-assembled MOTION-CONNECT power cables.
