6.5.6 Technical data
Technical data
Table 6-4 Line lters for Smart Line Modules
1)
Feature Unit 6SL5100-
0HE21-6DD0 0HE22-4DD0
Rated power kW 16 24
Power loss W 12 22
Weight kg 5.0 5.0
1)
Further, the same electrical rated values for the line lters apply as for the assigned Smart Line Modules.
More information
The technical data of the Smart Line Modules are provided in Chapter "Technical data
(Page124)".
6.6 Line reactors
6.6.1 Overview
Requirement
NOTICE
Damage to the system caused by line reactors that are not permissible
Line reactors that are not permissible can damage the Line Modules.
Line harmonics that damage/disturb other loads connected to the same line supply can also
occur.
• Only use line reactors that are listed in this Equipment Manual.
Line-side power components
6.6Line reactors
Booksize power units
Equipment Manual, 09/2023, A5E53307519B AA 107
