Requirement
WARNING
Electric shock if there is no ground connection
When the protective conductor connection of devices with protection class I is missing or
incorrectly implemented, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
• Ground the device in compliance with the applicable regulations.
The following requirements must be satis󹪝ed:
• The protective conductor must have the same cross-section as the line conductor of the line
supply cable.
• Use a suitable ring or tubular cable lug without insulation.
Width of Smart Line Module
[mm]
Rated power Ring/pipe-type cable lug
100mm 16kW and 24kW M5 (without insulation)
Required tools:
• Torx screwdriver TX25
Description
Connect the protective conductor to the protective conductor connection of the Smart Line
Module as follows:
1. Prepare the cable with a ring/tubular cable lug.
2. Connect the protective conductor to the component with the protective conductor
connection screw.
3. Tighten the screw. Torx screwdriver TX25. Tightening torque: 3Nm (26.6lbfin)
More information
Information on the protective conductor connection at the power plug is provided in the
following Chapters:
"Wiring a connection plug with screw connection (Page133)"
"Wiring the connection plug with push-in connection (Page134)"
