Table 7-7 Smart Line Modules C type (16kW and 24kW)
Feature Unit Article number: 6SL5130-
6UE21-6AC0 6UE22-4AC0
Power data
Rated power
at 380V/400V/480V
Maximum power
at 380V/400V/480V


kW

kW


16/16.8/20.2

35/37/44


24/25.3/30

48/51/61
Input data
Line voltage
Line frequency
Electronics power supply

V
Hz
V

3 AC 380 ... 480
50/60
24
Rated current (I
rated
)
Peak current (I
max
)
A
A
29
62
43
86
Output data
DC link voltage
Overvoltage trip
Undervoltage trip
1)

V
V
V

495...720 (typically 1.35xline voltage)
820
360...446
DC link current (I
DC link
)
DC link peak current (I
d max
)
A
A
33
71
49
97
Current-carrying capacity
DC link busbars
24 V DC busbars

A
A

200
20

200
20
Current consumption of the electronics
at 24VDC

A

0.70

0.70
Power loss W 150 200
DC link capacitance
Smart Line Module
Drive line-up, max.

μF
μF

820
20000

940
20000
Power factor cosφ 0.98
Cooling air requirement m
3
/h 77 77
Weight kg 8.2 8.2
Cable lengths m See Chapter "Maximum permissible cable lengths
(Page54)"
1)
Depends on the parameterized line voltage
Smart Line Modules
7.8Technical data
