Table 3-6 Climatic environmental conditions
Usage phase Description
Long-term storage Class 1K4 according to IEC60721-3-1:1997, in product packaging
1)
Temperature: -25… +55°C
Transport Class 2K4 according to IEC60721-3-2:1997, in transport packaging
2)
Temperature: -40… +70°C
Operation Class 3K3 according to IEC 60721-3-3:2002 with increased ruggedness with respect to
relative humidity
Temperature: -10 ... +40°C without reduction of the output current
>40 ... +55°C with reduction of the output current by 2.67% per°C
Relative humidity: 5… 95% no condensation (better than Class 3K3)
Oil mist, salt mist, ice formation, condensation, dripping water, spraying water, splash‐
ing water and water jets are not permitted
Table 3-7 Mechanical environmental conditions
Usage phase Description
Long-term storage Class 1M2 according to IEC60721-3-1:1997, in product packaging
1)
Transport Class 2M3 according to IEC60721-3-2:1997, in transport packaging
2)
Operation
Vibration test in operation



Shock test in operation
Class 3M1according to IEC60721-3-3:2002
According to IEC60068-2-6test Fc (sinusoidal)
• 10...57Hz: 0.075mm de󹪞ection amplitude
• 57...150Hz: 1g acceleration amplitude
• 10frequency cycles per axis
According to IEC60068-2-27test Ea (half-sine)
• 5g peak acceleration
• 30ms duration
• 3 shocks in all three axes in both directions
1)
Product packaging (storage packaging) is single unit packaging for storage - and does not satisfy the requirements for
transport. As a consequence, product packaging is therefore not suitable for shipping.
2)
Transport packaging is either packaging that is directly suitable for transport, or secondary packaging which, together with
the product packaging, satis󹪝es the requirements for transport.
