Table 4-14 Power losses for Single Motor Modules during rated operation (including losses of the
electronics)
Single Motor Modules Unit Power loss
3A W 29
5A W 40
9A W 65
18A W 150
24A W 189
30A W 261
30A(slim) W 272
45A W 344
60A W 486
85A W 760
132A W 1215
200A W 2010
Table 4-15 Power losses for Double Motor Modules during rated operation (including losses of the
electronics)
Double Motor Modules Unit Power loss
2x3A W 59
2x5A W 88
2x9A W 159
2x18A W 282
2x18A (slim) W 291
Table 4-16 Power loss of line 󹪝lters and line reactors for rated operation
Component Article number Unit Power loss
Line 󹪝lters for Smart
Line Modules
6SL5100-0HE21-6DD0 W 12
6SL5100-0HE22-4DD0 W 22
Line reactors for
Smart Line Modules
6SL3100-0EE21-6AA0 W 90
6SL5100-0EE21-6AD0 W 90
6SL5100-0EE22-4AC0 W 92
6SL5100-0EE22-4AD0 W 92
Application planning
4.13Power losses
