Siemens SINAMICS S220




0RWRU0RGXOHV
0RWRU
0RGXOH
0RWRU
0RGXOH
0RWRU
0RGXOH
$FWLYH
/LQH
0RGXOH
0RWRU
0RGXOH
0RWRU
0RGXOH
① DC link adapter
Figure5-6 Example of a three-tier con󹪝guration
For a multi-tier con󹪝guration, when connecting the DC link, observe the following additional
requirements:
• Locate the DC link adapter at the left-hand or right-hand side of the component.
• Only use single core and 󹪝nely-stranded conductors. Use shielded single cores and connect
the cable shield at both ends. The cables must be routed so that a ground fault or short-circuit
is completely ruled out.
Mounting
5.2Layout of the components
Booksize power units
86 Equipment Manual, 09/2023, A5E53307519B AA
