Introduction
1.2 Operator panel fronts
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
21
Key Function
<PAGE DOWN>
Scrolls downwards by one page in a window.
+
<PAGE DOWN> + <SHIFT>
In the program manager and in the program editor, from the
cursor position, selects directories or program blocks up to the
end of the window.
+
<PAGE DOWN> + <CTRL>
Positions the cursor to the lowest line of a window.
<Cursor right>
Editing box
Opens a directory or program (e.g. cycle) in the editor.
Navigation
Moves the cursor further to the right by one character.
+
<Cursor right> + <CTRL>
Editing box
Moves the cursor further to the right by one word.
Navigation
Moves the cursor in a table to the next cell to the right.
<Cursor left>
Editing box
Closes a directory or program (e.g. cycle) in the program
editor. If you have made changed, then these are
accepted.
Navigation
Moves the cursor further to the left by one character.
+
<Cursor left> + <CTRL>
Editing box
Moves the cursor further to the left by one word.
Navigation
Moves the cursor in a table to the next cell to the left.
