Creating a ShopMill program
7.17 Example, standard machining
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
251
Outside contour of the island
1. Press the "Contour milling", "Contour" and "New contour" softkeys.
The "New Contour" input window opens.
2. Enter the contour name (in this case: Part_4_island).
The contour calculated as NC code is written as internal subprogram
between a start and an end marker containing the entered name.
3. Press the "Accept" softkey.
The "Starting point" input window opens.
4. Enter the starting point of the contour.
X 90 abs Y 25 abs
5. Press the "Accept" softkey.
6. Enter the following contour elements and acknowledge using the
"Accept" softkey.
6.1. X 25 abs FS 15
6.2. Y 115 abs R 20
6.3. X 15 abs Y 135 abs
6.4. Y 155 abs R 10
6.5. X 60 abs R 15
6.6. Y 135 abs
7. Direction of
rotation
8. R 25 X 110 abs
9.1 Y 155 abs R 15
To Next Page
