Tool management

12.4 Tool dimensioning

Milling

470 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

/HQJWK

'LDPHWHU

&RUQHUUDGLXV

$QJOHIRUFRQLFDOWRROV

Figure 12-14 3D tool with an example of a bevel cutter with corner rounding (Type 156)

/HQJWK

'LDPHWHU

$QJOHIRUFRQLFDOWRROV

Figure 12-15 3D tool with an example of a tapered die-sinking cutter (Type 157)
