Tool management

12.4 Tool dimensioning

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

471

/HQJWKP

'LDPHWHU

/HQJWKX

Figure 12-16 Electronic workpiece probe

Machine manufacturer

The tool length of the workpiece probe is measured to the center of the ball

(length m) or to the ball circumference (length u).

Please refer to the machine manufacturer's specifications.

Note

An electronic workpiece probe must be calibrated before use.
