Functionsanddialogboxes
Relatedtopics
•Recordfunctiononpage157
•ReplayFiledialogboxonpage234
•EK500Datagramdialogboxonpage240
FileOutput;ProcessedData
UsethistabtosetuptheEK15toexportEK500
datagramstoîš¿le,andchoosewhichinformation
beincludedinthesavedîš¿le.
DataprocessedbytheEK15datacanalsobe
exportedtoaîš¿le.
TosupportprogramsusingdatafromtheSimrad
EK500echosounder,theEK15canoutput
EK500deîš¿neddatagramsonanEthernet(LAN)
output.Thesedatagramscanalsoberecorded
ontoaîš¿le.
Parameters
1SaveEK500
CheckthisboxtochoosetosaveEK500datagramstoîš¿le.
Note
Inordertodisablethisfunction,andtostoptheEK15fromsavingEK500datagrams
toîš¿le,youmustîš¿rstclearthischeckbox,andthenrestarttheEK15application.
2EK500Datagrams
ClickthisbuttontoopentheEK500Datagramdialogtosetuptheindividual
datagrams.
→EK500Datagramdialogboxonpage240
Topics
•FileOutput;Directoryonpage237
•FileOutput;RawDataonpage238
•FileOutput;ProcessedDataonpage239
Relatedprocedures
•Savingechogramsequences(rawdata)onpage54
Relatedtopics
•Recordfunctiononpage157
•ReplayFiledialogboxonpage234
•EK500Datagramdialogboxonpage240
351718/C
239
