Simrad SU90 Installation Manual

Settingtowork
Horizontalrange
Range
H-
Range
H+
Purpose
Checkthehorizontalrangeread-out.
Procedure
1PresstheMode2buttontoselectmode270°/Vertical.
2PresstheRangeH-andRangeH+buttonsintheRangeeldontheOperatorPanel
repeatedly.
3CheckthattheRangeread-outintheHorizontalmenuandonthetopofthetilt
indicatorchangesaccordingly.
[_____]Ok
Verticalgain
Gain
V-
Gain
V+
Purpose
Checktheverticalgainread-outs.
Procedure
1PresstheMode2buttontoselectmode270°/Vertical.
2ClicktheVerticaltabtobringupthismenu.
3PresstheGainV-andGainV+buttonsintheGaineldontheOperatorPanel
repeatedly.
4CheckthattheGainread-outintheVerticalmenuchangesfrom0to50.
[_____]Ok
Verticalrange
Range
V-
Range
V+
Purpose
Checkthehorizontalrangeread-out.
Procedure
1PresstheMode2buttontoselectmode270°/Vertical.
2PresstheRangeV-andRangeV+buttonsintheRangeeldontheOperatorPanel
repeatedly.
3CheckthattheRangeread-outintheVerticalmenuchangesaccordingly.
[_____]Ok
381293/A
177
