6ConnectthegroundingcablefromtheTransceiverUnittothemountingbracket.
[____]Ok
InstallationofTransceiverUnitwithgroundingcable
AUppershockabsorber
BTransceiverUnit
CHeatExchanger
DGroundingcable
EGroundingcable,detail
7Donotconnectthetransducercableconnector.
Thiswillbedonelaterintheinstallationprocess.
[____]Ok
80
381293/A
