Wilcoda motion controller
AXIS
port part pin definition
Pin
signal
description
6
A+
Encoder signal input
7
A-
8
B+
9
B-
5
AO+
Modulus output
10
AGND
Analog ground
Control line connections are as follows
Description :
1
, in order to pass control of the motion controller
Q 0
output, to control the servo drive is
enabled , need to servo drive external
DC24V
power to servo
DI
power (if the servo internal
selection is enabled, there is no need then
Q 0
and
DI 1
) ;
2
,
DIx
signal type (
NPN/PNP
) selection :
SW-DI
(
27
feet ) and
+24V
(
26
feet) are shorted
