Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
460
SlaveOffset
(Offset Slave axis
position)
Setting a position
offset Slave axis
(Unit: unit)
LREAL
Positive,
negative, 0 (0)
Exexcute
from FALSE to
TRUE
MasterScaling
(Spindle position
zoom ratio)
Set the scale of the
spindle position
LREAL
A positive
number
(Non-default)
Exexcute
from FALSE to
TRUE
SlaveScaling
(Scaling ratio Slave
axis position)
Axis scale is set from
the position
LREAL
A positive
number
(Non-default)
Exexcute
from FALSE to
TRUE
SlaveRange
(Slave axis of the
cam phase range)
Setting range from the
phase of the cam shaft
LREAL
MasterSyncPosition
(Reserved)
Retention
ActivationPosition
(Engagement
start position)
Setting the
engagement process begins
when the main shaft
position, i.e. the position
when the spindle passes,
from the shaft engagement
operation started
(Unit: unit)
LREAL
Positive,
negative, 0 (0)
Exexcute
from FALSE to
TRUE
ActivationMode
(Mode boot mode)
Engagement start
position setting mode
INT
0: the relative
position of the axis
1: Absolute
shaft position
2: Absolute
phase axis
3: Absolute
cam phase
(0)
Exexcute
from FALSE to
TRUE
StartMode
(Engaging mode)
Performing
engagement operation
mode is set from the shaft
INT
0: The
shortest distance
1: Forward
2: Reverse
Exexcute
from FALSE to
TRUE
Velocity
(speed)
Maximum meshing
operation setting execution
process allows stacking
velocities from the shaft
(Unit: unit / S)
LREAL
A positive
number
(Non-default)
Exexcute
from FALSE to
TRUE
Acceleration
(Acceleration)
Maximum
engagement setting
operation performed during
、
LREAL
A positive
number
(Non-default)
Exexcute
from FALSE to
TRUE
