VA Motion Controller Programming Manual

496

name

Numerical

Analog input voltage (V)

0 ~ -10 ~ + 10

Digital

0 ~ 2048 ~ 4096

(2)The experimental results (due to the presence of an error, there will

be fluctuations in the corresponding digital value for reference)

Input voltage(V)

Digital

2028

2434

3043

3653

4060

-10

-8

403

-5

1012

-2

1621

2027

(3)Test table obtained by the analog input and the amount of data relationship

diagram
