VA Motion Controller Programming Manual
510
Set_Count
(Set the
current count of
pulses)
High-speed counter
current value setting
Description:
(1) 5-way motion controller integrated with hardware high speed counter respectively port
AXIS0 ~ AXIS4 (currently only supports the AB phase signal), the counting is not affected by a
pure hardware scan cycle, the maximum count frequency is 1MHz. 5-way counter port 7 can be
called high-speed counter module AXIF_no (counter number) from 0 to 6, respectively, are
opposite to each other counting methods, without disturbing each other.
(2) This command integrates feature-rich, containing DI external start, the counter is cleared,
and clearing the counter variable start, cycle counting function, set the number of functions,
(3) sources by pulse counter Active_Axis (axis current count) is selected, any given, but also
cross-axis counting function.
(4) high-speed counter-rich functional integration, can be selected according to requirements,
function of the input parameters to an unused blank.
(5) Start the external terminals DI internal high-speed counter has been specified, when a
high number counter, when DI_Start_Valid is TRUE, the terminal being used as the external DI
start high-speed counter input terminals, when DI_Start_Valid is FALSE, but when an ordinary I /
O using the following specific distribution
Specifies the external
terminals DI as the start
counter signal high
Optional (not allowed to repeat with
DI start)
Optional (not allowed to repeat with
DI start)
Optional (not allowed to repeat with
DI start)
Optional (not allowed to repeat with
DI start)
Optional (not allowed to repeat with
DI start)
Optional (not allowed to repeat with
DI start)
Optional (not allowed to repeat with
DI start)
Output parameters
