VA Motion Controller Programming Manual
513
Case 1:When counter_enable FALSE to TRUE grounds, and maintained. di_start_Valid
becomes TRUE, and if the external signal DI3 signal is valid, the counter 3 starts counting the
number of high, Count_out display the current pulse when the rising edge DI0 di_reset_no
specified, the current value of the high-speed counter is cleared.
Demonstration program Ⅲ
Example: outer boot and the external terminals DI0 DI3 is cleared, and sets the number of
pulses axif_counter external shaft section DI valid counter is cleared
1. variables, and procedures
