VA Motion Controller Programming Manual
529
valid bit level)
DI_Reset_Valid_
DEdge
(External falling
edge bit is cleared)
When DI_Reset_Valid_
Dedge is TRUE, DI cleared
the falling edge clear
BOOL
TRUE or
FALSE
DI_Reset_Valid_
UEdge
(External DI clearing
rising significant bit)
When DI_Reset_Valid_
Uedge is TRUE, DI cleared
to rising cleared
BOOL
TRUE or
FALSE
DI_Reset_No
(External DI
cleared)
Specifies the external
clear signal terminal, the
input value of 0 to 7
corresponding to the input
point I0 ~ I7,8 ~ 15
corresponding to the input
point I10 ~ I17
WORD
0 ~ 15
U_D
(Bit counting
direction)
Counting direction
specified counter
0: Negative counting
direction
1: positive counting
direction
DINT
0 or 1
Count_Cycle_Va
lid
(Cycle Count
Valid bits)
When Count_Cycle_Valid
is TRUE, start the counting
cycles when the counter
value reaches the counter
Count_Cycle set value, the
new count is automatically
cleared, constant cycle.
Count_Cycle_Valid to
FALSE when not enable
this feature.
BOOL
TRUE or
FALSE
Count_Cycle
(Setting DI loop
counter value)
When Count_Cycle_Valid
is TRUE, start the counting
cycles when the counter
value reaches the counter
Count_Cycle set value, the
new count is automatically
cleared, constant cycle.
Count_Cycle_Valid to
FALSE when not enable
this feature.
DINT
Positive,
negative,
