Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
624
4.1.2 Reset the Master-slave Node
 Input parameters
variable name
Features
type of data
The initial value
Axis0
(axis number)
Node number = axis number +1
USINT
0
C000
(execute bit)
When the Execute FALSE to
TRUE, the instruction is
executed
BOOL
FALSE
1, NMT_Mode (network model) is customizable, template is defined as: 1 (Start Network), 2
(stop the network), 4 (the network into a pre-operation), 8 (reset node), 16 (reset communication),
this selected at NMT_Mode = 8, reset the network;
2, the internal module functions NS_CC_CANopen_NMT_Write two modules, one master
station 18 is reset, one pair of the station 1 is reset from the node number, the condition "C000"
trigger time delay waiting for approximately 1s and then go to the next step. (See detailed
configuration template "Vector CANopen Configuration")
