Virtex-6 FPGA GTX Transceivers User Guide www.xilinx.com 65

UG366 (v2.5) January 17, 2011

Implementation

X-Ref Target - Figure 1-28

Figure 1-28: Placement Diagram for the FF1154 Package (5 of 12)

HX250T:GTXE1_X1Y7

HX380T:GTXE1_X1Y7

HX250T:GTXE1_X1Y6

HX380T:GTXE1_X1Y6

HX250T:GTXE1_X1Y5

HX380T:GTXE1_X1Y5

HX250T:GTXE1_X1Y4

HX380T:GTXE1_X1Y4

QUAD_111

AB5

AB6

AF1

AF2

AC3

AC4

AH1

AH2

AC8

AC7

AE8

AE7

AD5

AD6

AJ3

AJ4

AE3

AE4

AK1

AK2

MGTTXP0_111

MGTTXN0_111

MGTRXP0_111

MGTRXN0_111

MGTTXP1_111

MGTTXN1_111

MGTRXP1_111

MGTRXN1_111

MGTREFCLK0P_111

MGTREFCLK0N_111

MGTREFCLK1P_111

MGTREFCLK1N_111

MGTTXP2_111

MGTTXN2_111

MGTRXP2_111

MGTRXN2_111

MGTTXP3_111

MGTTXN3_111

MGTRXP3_111

MGTRXN3_111

UG366_c1_28_111110

Right Edge of the Die
