4. Diagnostics
4.4.3.2 Input frequency
Why necessary
The projector needs to know the frequency of the input signal presented to the projector so that it can
calculate internal synchronization parameters.
How to select
1. Tip on one of the radio buttons in the Input frequency field. (image 4-28)
Possible choices :
- 23.98 Hz
- 24.00 Hz
Image 4-28
Input frequency selection
4.4.3.3 Timeline stamp
Only available for an internal time source.
What is the purpose
The internal time code will be set to the value of the timeline stamp. The image displayed will be the image
with eventually the subtitling overlay at the time of the timeline stamp. When the play button is pressed,
the time code starts running from the value in the timeline stamp.
How to enter a timeline stamp
1. Tip on the hours, minutes or seconds value and enter the new value with the digit keys of the keyboard
Or,
tip on the hours, minutes or seconds value and tip then on the up down control of the spin box to change
the value to the desired one. (image 4-29)
Tip: Use the bottom right button to display or hide the keyboard.
2. Tip on Apply time now to apply the new time to the time code.
Image 4-29
Set up timeline stamp
4.4.3.4 Timeline adjustment
Only available for an internal time source.
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012 109
