3. Configuration
Image 3-19
Save to macro
3.6 Screen
Overview
• ActivateaSCREENfile
• Resizing the image
• Masking the image
•Savetofile
• SavetoMacro
3.6.1 Activate a SCREEN file
Screen File
Screen presentation configuration file. This file contains information about resizing, letterbox-
ing, masking and lens factor.
How to activate a SCREEN fi le
1. While in Configuration,tiponSCREEN.
The Image overview is displayed.
2. Tip on Activate a SCREEN file (1). (image 3-2
0)
The Select a SCREEN file window opens (2).
3. Browse to the desired SCREEN file and tip on it to select (3).
4. Tip on OK (4).
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
49
