Barco DP2K Series User Manual

2. Controls
2.1.2 Activating a preset
How to activate
1. Tip on the button next to the desired description. To activate a preset on another preset page, tip first
on that preset page and then on the desired button.
The macro behind the selected preset will be executed. A hourglass appears on the macro button.
As an indication that the preset is activated, the button changes to blue. (image 2-2, image 2-3)
Image 2-2
Activation process is running
Image 2-3
Preset status
A Not activated
button
B Activated button
When a preset is activated and a warning sign appears on the preset, that means that
an error occurs while executing the command lines of the macro file. Tip on that sign
to get more info.
Image 2-4
2.1.3 Lamp On/Off
What can be done?
The projection lamp can be switched ON and OFF using the toggle button on top of the preset pane.
Image 2-5
Lamp on/off button
Toggling the lamp status
1. When the button is in a not pressed status, tip the button to switch the lamp ON.
2. When the lamp is ON, button indicates blue, tip this button again to switch off the lamp.
2.1.4 Dowser Open/Close
What can be done?
With this permanent preset you have full control over the dowser setting. With a tip it is possible to open
or close the dowser.
18
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
