5. Installation
Mode Explanation
LENS Lens data file.
Stores information about the lens adjustment in a typical setup.
LSC Light sensor calibration file
Stores information about the calibration setting according the light output for a
certain type of screen.
Image 5-35
File selection
How to change the view for Local files
1. Tip on the drop down box to select the local medium. (image 5-36)
The following mediums are possible:
- Touch panel
- One of the 2 USB connections.
Image 5-36
Local file selection
5.9.3.4 Create new local folder
How to create
1. Tip on the drop down box and select the physical medium (1). (image 5-37)
The medium can be the touch panel or one of the two USB connections.
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
159
