2. Controls
Image 2-16
Removing test pattern
2.3 Service
Overview
• About the service settings
• Lamp and lamp information
• Light output mode
2.3.1 About the service settings
To open the service settings
Click on Service in the tab page pane.
The following items are available:
• The current light out
• Lamp current
• Lamp information
• Lamp output mode
2.3.2 Lamp and lamp information
Current light output
The current light output is indicated in FootLambert.
Image 2-17
Lamp power and light output information
It indicates also in which mode the projector is working.
