8. Macro editor
8.4.2 3D extended
8.4.2.1 Activate MCGD2
What can be done ?
When the color path selection is set to dual (left and right eye separately), the measured color information
for the right eye must be added via a macro.
How to select
1. Tip on Activate MCGD2 file.
The right pane shows the current selected file. (image 8-23)
2. Tip on Select file.
A files overview window is displayed. (image 8-24)
3. Select the desired file out of the list and click OK.
Or,
double click on the desired file.
The selected file name appears next to Filename.
Image 8-23
Activate MCGD2 file
Image 8-24
Select MCGD2 file
262 R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
