Barco DP2K Series User Manual

3. Configuration
Input selection
Source selection
292 3D
Frame rate Multiplication 46:2
3D settings
L/R Input Reference Use Line interleave where first
line = Left second line = Right
Set 3D Dark Time adjustment, 3D L/R Output Reference Delay and 3D L/R Output Polarity as needed.
3.7.2.2 Start up the 3D settings
How to start up
1. While in Configuration, tip on the double arrow downwards to open extra menu options and select 3D.
The 3D overview is displayed.
2. Tip on 3D settings.(image3-38)
The 3D Control window opens.
Image 3-38
3D settings
3.7.2.3 Frame rate multiplication
Introduction
The system provides the capability to do frame rate multiplication based on an N/M system.
68
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
