5. Installation
Image 5-9
Light sensor calibration
Create new calibration file
1. Enter the footlambert value to be used in the new calibration file (5).
2. Tip Save (6).
A browser window opens. Enter a file name and tip Save.
The new fileisreadytobeusedasLSCfile.
It only makes sense to create a LSC file when the lamp is on !
ALSCfile can be recalled from a macro.
5.3 Lamp alignment
5.3.1 About lamp alignment
Overview
Due to ageing of the lamp, the light output will be reduced if no corrective actions are taken. To bring
the light output again on its normal level, lamp alignment should be performed on a regular time. Also
when the lamp is replaced physically the alignment procedure has to be done. Normal Z-axis alignment is
enough to bring the light output ag
ain on its normal level. But sometimes, alignment of the other axes are
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
127
