Barco DP2K Series User Manual

3. Configuration
How to select
1. While in Configurator,clickonInput.
The Input overview is displayed.
2. Click on Input settings (1). (image 3-12)
3. Click on MED tab.
4. Select he correct parameters
Mode Type Type parameter
Color calibration
Single (default)
4:2:2 Progressive
-
Dual (separate eye)
Single (default)
4:4:4 Progressive
-
Dual (separate eye)
5. Click Close (7).
Image 3-12
Input settings, mediablock
3.4.5 Save to file
What can be done ?
The input settings can be saved to file. This filecanbeusedtocreateorupdatemacros.
How to save
1. While in Configuration,tiponInput. (image 3-13)
The Input overview is displayed.
2. Tip Save (1).
The file selection window opens (2).
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
43
