Barco DP2K Series User Manual

3. Configuration
• A : input source
•B:
- Resized area equals the maximum DMD size
- The input image has a different aspect ratio from the resized area.
- Full image is letterboxed (top and bottom) and centered within the resized area.
•C:
- The screen height is narrowed, bottom is moved upwards.
- The input image has a different aspect ratio from the resized area.
- Full image is letterboxed (top and bottom) and centered within the resized area.
•D:
- Bottom of resized area is moved upward to where image fills this area.
- The input image has now the same aspect ratio from the resized area.
- Full input image centered within the resized area and letterboxing is not required.
•E:
- Bottom of resized area has moved upward to where image at previous size cannot be fully dis-
played.
- Resized area reduced in both directions (maintaining aspect ratio) so full scaled image can be dis-
played.
- Image is letterboxed ( right side and left side).
Letterbox disabled
56
R59770488 COMMUNICATOR TOUCH PANEL 06/06/2012
