3. Installation Marathon Express
Installation Procedure Part Number: 605914 Rev. B
Donotraisethenon-supportingfeetmorethan1mmfromthefloortoensurethatthesystemisnotallowedto
“twist”asthiscoulddamageanycomponentsconnectedtothesystemandcouldcauseapotentiallyunsafe
operatingenvironment.

Step Action
1.
Lowerthelevelingfeet,showninFigure3-2,untilthefeetarefullysupportingthemodule’sweight.
Figure 3-2: Lowering the Leveling Feet
2.
Raisethewheelsandremovethecasters.Retainthecastersforfutureuse.
NOTE: ThecastersmustbesavedforfutureuseinmovingtheMarathonExpress.
