Brooks Automation 3. Installation
Part Number: 605914 Rev. B Power-up Sequence
Step Action
10.
TurnonthepowerwithintheMarathonExpresssystem.
TurnontheMainBreakerfortheACPowerDistributionUnit,locatedonthefrontoftheunitasshown
inFigure3-11.

Figure 3-11: AC Power Distribution Unit
11.
PerformaGroundContinuitycheckfromthesurfacesoftheMXsystemandallrackmountableequip-
menttoaknowngoodground.
12.
ThemoduleswillpowerupwhentheMainBreakerontheACPDisturnedonandthefollowingsounds
andindicatorsshouldbeobserved,refertoforanoverviewoftheindicatorsthatshouldbeon.
l
Audiblesounds:fansinrobotdrive

Iftheinitializationsequenceexecuteswithouterror,thentheBrooksAutomationMarathonExpress
hasbeenproperlyinstalled,allthecomponentsarecommunicatingsuccessfully,andthesystemis
readyforoperation.
NOTE: TheHostControllerinitiatesallmotioncontroltotheMarathonExpress.Ifbitsarehighat
start-up,motionwilltakeplace.Itistheuser’sresponsibilitytoinitiateasafestart-upoftheMarathon
Expresssystem.
NOTE: Ifstart-upwassuccessful,theMarathonExpressisreadytoacceptcommands.If,however,
thestart-upsequencewasunsuccessful,referto"InitialTroubleshooting"onpage203.
13.
ReturnMarathonExpresssystemtooperationorteachtheMXsystemasrequired.

TheBrooksAutomationMarathonExpresssystemmustbealignedwiththesystemthatitwillbe
operatingintopreventmisplacementofthematerialbeingmovedthroughthesystemorcollisionof
therobotwithotherpartsofthesystem.Notethatevenasmallmisalignmentcaninterferewith
properMXsystemoperationandmaycausematerialbreakageorMXsystemdamage.
TheusermustperformacompletealignmentaspartofinstallingtheMXsystem.
Referto"SystemAlignment"forthealignmentprocedures.

