2. Insert the respective attachments for the roll paper core on the Roll Holder and Holder Stopper.
•
Using rolls with a 2-inch paper core
Holder Stopper Side Roll Holder Side
Align the tips (a) of the 2-Inch Paper Core Attachment with the holes (b) of the Holder Stopper
and insert it firmly.
No attachment is
needed.
•
Using rolls with a 3-inch paper core
Holder Stopper Side Roll Holder Side
Align the tips (a) of 3-Inch Paper Core Attachment #2
with the holes (b) of the Holder Stopper and insert it
firmly.
Align the tips (a) of 3-Inch Paper Core Attachment #1 with
the holes (b) of the Roll Holder and insert it firmly.
Handling Paper
>
Handling rolls
>
Attaching the Roll Holder to Rolls iPF8300
7
776
