a.
Weight Roll (6)
Weights required when rewinding rolls. Use one weight roll or combine two (with a Weight Joint ), depending on the
roll width.
b.
Weight Joint
Fastens two weight rolls.
c.
Weight Flange (2 sets)
Attached to the ends of Weight Roll to adjust the weight. Use Weight Flange 1 or Weight Flange 2, depending on the
type of paper. (See "Loading the Rewind Spool on the Media Take-up Unit.") →P.823
Printer Parts
>
Printer parts
>
Media Take-up Unit (Optional) iPF8300
