11Service Manual – CS7010™
03 - General Information
General Machine Description
The CS7010 machines are industrial automatic rider sweeper/scrubbers with multiple sweep/scrub single-
pass coverage. Both battery (all electric) and hybrid (engine) models are available with or without the
EcoFlex
™
and DustGuard
™
options. The scrub system uses three disc scrub brushes with variable scrub
pressure and solution ow rates. The sweep system has a center main broom and left- and right-hand side
brooms.
The fuel cell powered model is similar to the battery model in construction, except it is designed to
accommodate an approved fuel cell provided by Plug Power.
Service Manual Purpose and Application
This Service Manual a technical resource designed to aid service personnel in maintaining and repairing the
CS7010 Sweeper/Scrubber to ensure optimum performance and long service life. Please read it thoroughly
before servicing your machine.
Revision History
Revision Summary of Changes
5/2017 First Release
7/2017 • Updated electrical schematic to Rev B.
• Added main broom motor carbon brush replacement procedure
11/2017 •
Addedrmwareupdateprocedure
• CorrectedKGSTpassword
• Updated Drive and Steering error codes
• Notedsteeringshaftsetscrewpositioning
