Crescent CS7010 - Side Broom Motor Carbon Brushes

275Service Manual – CS7010™ 48 - Sweep System, Side Broom
Side Broom Motor Carbon Brushes
1. Remove the Side Broom Motor described on page 277.
2. Create witness marks on the gearbox, motor end bells
(covers) and the motor casing for reassembly.
3. Loosen the wire retaining nut and remove the two through bolts. Do not lose or damage the rubber
washers.
4. Remove the end cover. Do not lose or damage the O-ring seal.
O-ring
Carbon
Brushes
