Crescent CS7010 - Squeegee System; Functional Description; Overview; Squeegee and Recovery Wiring Diagram

240Service Manual – CS7010™
38 - Squeegee System
Functional Description
Overview
The squeegee assembly is mounted at the bottom rear of the machine and picks up the water from the oor.
Two squeegee blades (front and rear) pick up the water and direct it into the squeegee support assembly.
A vacuum hose attached to the support assembly lifts the water from the squeegee and directs it to the
recovery tank. The squeegee lift actuator raises and lowers the squeegee as appropriate for the operation
being performed. The actuator is driven by the power module #2 via commands from the Main Controller.
The squeegee mounting system is designed to allow the squeegee blades enough side-to-side movement to
conform to the oor surface and swing sideways when turning.
Squeegee and Recovery Wiring Diagram
B-
BLK
A1
MAIN MACHINE
CONTROLLER
J1-19
J1-6
J1-30
VACC2
VACC1
VACC2
J1-29
TO 1A3, 1D2
RED BLK
BLK-ORN
YEL-BRN
YEL-BRN
RED
RED
VIO
B-
BT1
BATTERY, 36VDC
+
-
X166
K1b
MAIN RELAY
1
2
X169
K1a
MAIN RELAY
CB1
IGNITION SW 5 AMP
1 2
CB2
VACC2 25 AMP
1 2
F1
FUSE, 400 A.
1
2
START
KSI Input
J1-21
VIO-GRN
ORN
ORN
fiflfl
fi

SW1
SWITCH, IGN.
BAT
ON
ST
Telematics
Jumper
J1-33
VIO VIO-ORN
B-
M
M21
PUMP, EXTENDED SCRUB
_
+
J2-10
BLKGRY-YEL
+5V
SW7
SW, EXTENDED SCRUB
LEVEL(OPTIONAL)
1 2
M4
M5
BLU-GRY
BLU-GRY
GRY-RED
ORN-BLU
B-
B-
M
M4
MOTOR, VACUUM 1
12
M
M5
MOTOR, VACUUM 2
1
2
J4-13
J4-14
VIO-BLU
BRN-WHT
B-
B+
M
M16
SQUEEGEE ACTUATOR
+
_
B-
B+
J4-2
A2
POWER MODULE
KSI
B+
B-
J4-9
BRN-GRN
GRN-GRYRED
BLK
ORN
ORN
K2a
COIL, POWER MODULE
3 4
K2b
POWER MODULE
2
1
B-
KSI (Control Power) to Power Module
High Power to Power Module
J4-2
A3
POWER MODULE
KSI
B+
B-
J4-9
TO 3B2
BRN-GRN
GRN-GRYRED
BLK
ORN
ORN
K3a
COIL, POWER MODULE
3 4
K3b
POWER MODULE
2
1
B-
KSI (Control Power) to Power Module
High Power to Power Module
V
ACC2
Power
