245Service Manual – CS7010™ 38 - Squeegee System
Squeegee Casters Adjustment
The height of the squeegee casters may need to be adjusted to
compensate for squeegee wear and to obtain the correct squeegee tilt
angle. To adjust the height of a squeegee caster:
1. Loosen the locknut.
2. Use a wrench on the ats of the threaded shaft to turn
the threaded shaft to raise or lower the squeegee caster as
necessary.
3. When the squeegee caster is at the correct height, tighten the
locknut.
4. Check the squeegee tilt angle and adjust as necessary. (Refer to
the to adjust the squeegee tilt section on the preceding page.)
Troubleshooting
Problem Cause Correction
The squeegee is not
pickingupthewater
effectively.
Thereisavacuumleak
betweenthesqueegee
weldmentandtherecovery
tank.
• Makesurethesqueegeehoseisinstalledcorrectly
intherecoverytankandonthesqueegeeweldment.
• Checkthesqueegeehosefordamageorcracksand
replace if necessary.
The squeegee blade(s) is/are
wornout.
• Flipthesqueegeeblade(s)aroundtopositionanew
bladesurfaceontheoor.
• Replace the squeegee blade(s).
The squeegee actuator is not
loweringthesqueegeefar
enoughontotheoor.
Thesqueegeedowntimeisnotsetcorrectly.Referto
the Control System/Troubleshooting/Hidden Menus/
UserOptionsMenusection.
The squeegee is not
pickingupthewater
consistently along the
entire length of the
squeegee.
The squeegee tilt need to be
adjusted.
Adjustthesqueegeetilt.(RefertotheMaintenance
andAdjustments/ToAdjusttheSqueegeeTiltsection.
Threaded
Shaft
Locknut
Squeegee
Caster
