243Service Manual – CS7010™ 38 - Squeegee System
Rear Squeegee Blade
1. Release the latch and remove the
squeegee strap.
2. Remove the rear squeegee blade
from the squeegee weldment.
3. Rotate the existing rear squeegee
blade top-to-bottom or end-for-end
to position a new blade surface
on the oor, or install a new rear
squeegee blade onto the squeegee
weldment pins.
4. Reinstall the squeegee strap, then
close the latch.
Squeegee End Wheels
Once a month apply light machine oil to the squeegee end wheels.
Squeegee Caster Wheel Bearings
Once a month pump a small amount of grease into the grease tting on
both caster wheels on the squeegee support assembly until grease seeps
out around the bearings.
Latch
Squeegee
Weldment
Squeegee
Strap
Rear
Squeegee
Blade
Squeegee End
Wheel (2)
Grease
Fitting
