Crescent CS7010 - Programming Menu Outline

39Service Manual – CS7010™ 04 - Control System
Programming Menu Outline
Hours
On Time
Drive Time
Scrub Time
Recovery Time
Engine Time
Sweep Time
Faults
Active Faults
Fault History
Clear History
Service
A1 Main Controller
A2 Power Module 1
A3 Power Module 2
A4 Drive Controller
A5 Steering Contr
Engine
Output Test
Panel Test
System
Firmware
Serial Number
Install Firmware
A4 Drive Controller
J1-1 Throttle 1
J1-2 Throttle 2
J1-3 Hi Press Pump
J1-4 Glowplug
J1-5 Headlights
J1-7 Ignition
J1-8 Solution Valve
J1-9 Engine Start
J1-10 E-Stop
J1-11 Interlock
J1-12 Seat Switch
J1-13 12V
M19/20 Det Pumps
J1-18 Backup Alarm
J1-20 Rt Turn
J1-21 Key Start
J1-22 Eng Run V
J1-23 KSI
J1-24 Tailights
J1-33 Ext Scrub Pump
J1-35 Horn
J2-8 Filter Plugged
J2-9 Brake Switch
J2-10 Ext Scrub Sw
J2-13 Hopper Down
J2-14 Hopper Temp
J2-15 Eng Temp
J2-16 Oil Pressure
J2-17 Dump Door V
J2-18 Dump Door Close
J2-20 Eng MIL
J2-22 Main Broom V
J2-23 Fuel Level V
Sol Level V
J1-25 Lt Turn
J1-26 Dust Guard
J1-28 Solution Pump
J1-30 VACC 2
J1-31 Lt Stop
J1-32 Rt Stop
A1 Main Controller
M11 Hopper %
→ %Req, %Out, A
M13 Ctr Brush %
→ %Req, %Out, A
M14 Lt Brush %
→ %Req, %Out, A
M15 Rt Brush %
→ %Req, %Out, A
M16 Squeegee %
→ %Req, %Out, A
M17 Deck %
→ %Req, %Out, A
M18 Side Brm Act %
→ %Req, %Out, A
A3 Mod: B+, Deg C
A3 Power Module 2
= Service-Only Access
Some Abbreviations Spelled Out
M1 Main Broom
→ %Req, %Out, A
M2 Dust Fan
→ %Req, %Out, A
M3 Side Broom
→ %Req, %Out, A
M4 Vacuum 1
→ %Req, %Out, A
M5 Vacuum 2
→ %Req, %Out, A
M6 Main Brm Act
→ %Req, %Out, A
M7 Dump Door
→ %Req, %Out, A
M8 Shaker
→ %Req, %Out, A
A2 Mod: B+, Deg C
A2 Power Module 1
Type
J1-1 Throttle 1
J1-2 Throttle 2
J1-4 Glow Plug
J1-7 Ingnition
J1-9 Eng Start
J1-13 12V
J1-21 Key Start
J1-22 Engine Run V
J2-15 Eng Temp
J2-16 Oil Pressure
J2-20 Eng MIL
J2-23 Fuel Level V
Total Amps
Engine
Speed (mph/kph)
Max RPM
R4 Throttle %
R4 Throttle V
M9 Encoder RPM
M9 Motor RPM
M9 Motor RMS Amps
M9 Motor DC Amps
M9 Motor degC
A4 degC
B+ V
J5-4 K4 Enable
J5-28 E-Stop
J5-12 Seat Switch
J5-19 Drive Enable
E1 TFD Angle
Steer Angle
E1 TFD RPM
J6-27 L Limit Sw
J6-15 R Limit Sw
M10 Encoder Angle
M10 Encoder RPM
M10 Motor RPM
M10 Motor RMS Amps
M10 Motor DC Amps
M10 Motor DegC
A5 Ctrl degC
B+ V
J6-13 K5 Enable
J6-4 Drive Enable
J6-24
TFD Enable
A5 Steering Controller
Output Test
H1 Backup Alarm
H2 Horn
L2 Sol Valve
LT2-4 Headlights
LT5 LF Turn
LT6 RF Turn
LT7,8 Taillights
LT9 LR Turn
LT10 RR Turn
M19,20 Det Pump
M21 Ext Scrub
M22,L1 Dust Grd
M23 Sol Pump
Y1 Hi Press Pump
M1 Main Broom %
M2 Dust Fan %
M3 Side Brooms %
M4 Vacuum 1 %
M5 Vacuum 2 %
M6 MB Act %
M7 Dump Door %
M8 Shaker %
M11 Hopper %
M13 Ctr Brush %
M14 Rt Brush %
M15 Lt Brush %
M16 Squeegee %
M17 Deck %
M18 SB Act %
Eng Speed
Options
Scrub Start
Scrub Max
BOP Time (s)
Solution Mode
Solution In Rev
Shaker Time (s)
Broom Up In Rev
Max Speed (%)
Lock Speed Limit
Headlight
Steer Home Enable
Language
Configuration
Machine Type
Brand
Ecoflex
Dust Guard
Ext Scrub Kit
Back-Up Alarm
Signal Light Kit
Plugged Filter Kit
Hopper Temp Kit
Hi-Press Pump Kit
Display
TrackClean
Deck Down Time (s)
Neutral Delay (s)
Sqg Up Time (s)
Eng Idle Delay (s)
Dump Door Open V
Vac Off Delay (s)
Detect RTF
Some Entries Grouped for Brevity
