46Service Manual – CS7010™ 04 - Control System
Troubleshooting
When troubleshooting the machine, the CS7010 main controller should be one of the rst steps for most
troubleshooting scenarios. All of the distributed controllers throughout the system report their status back
to the main controller, including error codes. So when any of the controllers, including the MMC itself,
experience any sort of fault, the operator’s interface will display that/those fault(s).The tables in the next
section below describe each of these error codes, along with possible causes and remedies.
Many error codes will disable the applicable function to protect components, and may require the machine to
be reset in order to clear the condition prior to testing.
Another troubleshooting tool is the Output Test function in the service menu, and described on page 42.
Use the output test to manually activate devices to be able to make sound, heat, vibration observations, as
well as electrical measurements.
Fault Codes
All error codes are presented as 4-digit numbers (x-yyy), where the rst digit represents which controller is
reporting the error, and the remaining digits identify the actual error code.
• 1- indicates the A1 Main Controller , below
• 2- indicates the “A2 Power Module #1” on page 49
• 3- indicates the “A3 Power Module #2” on page 52
• 4- indicates the “A4 Drive Controller” on page 55
• 5- indicates the “A5 Steering Controller” on page 57
A1 Main Controller
Fault
Code
Description Level Condition
1-001
K1CoilOpen Critical The controller commanded the K1 relay to close, but no input
voltagewasdetectedatVACC2.
• TheK1relayusesredundantcontacts,sothelikelycause
isrelaycoilfailureoranopencircuitinthewires.
1-002 K1 Coil Short Non-Critical The controller has detected high current (more than 5 amps)
totheK1relaycoil.Checkthecoil.Checkthewiresforshorts.
1-003 K1 Contact Weld Non-Critical The controller is detecting voltage present at the VACC2
input, but the K1 relay is not commanded to close
• Disconnecttherelayoutputwires.Iftheconditionpersists,
thenitisknowntobeashorttoBat+inthewires.
• Iftheconditionclearsafterdisconnectingtheoutputwires,
thenitisknownthatthecontactshavefusedandtherelay
must be replaced.
1-010 CAN Bus 0 Critical CAN bus 0 is in bus-off state. The controller has seen no
response from other controllers on the bus.
1-011 CAN Bus 1 Critical CAN bus 1 is in bus-off state. The controller has seen no
response from other controllers on the bus.
