16Service Manual – CS7010™ 03 - General Information
Lifting the Machine
CAUTION: Never work under a machine without safety stands or blocks to support the machine.
When lifting the machine, do so at the designated Tie Down/Support Locations.
Transporting the Machine
CAUTION: Before transporting the machine on an open truck or trailer, make sure the machine
is tied down securely and all access doors and covers are secured (tape and strap as
needed).
The lifting and tie-down locations are identied with a graphic molded
into the exterior body panels.
The jacking and tie-down locations are in front of the front wheels, and at the rear of the machine below the
solution tank.
Rear Support/Tie-down LocationFront Support/Tie-down Location
Jacking/
Tie-down
Location
