177Service Manual – CS7010™ 28 - Engine System, Diesel
Special Tools
Diesel Compression Gauge
There are many brands of compression gauges
available.
ShownisaSnap-OnEEPD500Gaugekit
CompressionGaugeFittingforGlowPlugthreads.
ShownisSnap-OnTU-15-35
Threads-M8X1.0
Gauge Coupler
IfusingtheSnap-OndieselcompressionEEPD500
GaugekitandSnap-OnTU-15-35glowplugthread
tting,acouplermustbeusedtojointhettingtothe
gaugehose.ShownareSnap-OncouplersM3569
and M3570
